SETS-THIRAL-PRINCE-EM-UnProtected-FPGA

About Dataset

The traces were obtained by measuring the real-time EM emission of an PRINCE encryption process. These measurements are highly suitable for Side-Channel Analysis (SCA), enabling cryptographic key recovery through both statistical techniques and deep learning–based approaches. EM traces were collected using KeySight DSOS204A Oscilloscope, with the bandwidth of 2GHz and Sampling rate of 20GS/s connected to an Kintex-7 FPGA. Trigger-based synchronization is used during acquisition process to align the captured traces with encryption operations. After collection, the traces were formatted and annotated with appropriate labels to support side-channel analysis experiments and AI model development. The dataset is provided in HDF5 (.h5) format and is divided into Profiling_traces and Attack_traces groups. The Profiling_traces group consists of 100,000 EM traces, each containing 70,002 sample points along with a metadata structured array containing the corresponding plaintext, key, and ciphertext values and a label array. The Attack_traces group contains 20,000 EM traces together with the corresponding metadata structured array. The labels correspond to the most significant nibble (MSB nibble) of the first-round S-box output for byte 0 of the plaintext. Label generation uses plaintext byte 0 (PT [0]) and the 128-bit PRINCE master key. The master key is divided into two 64-bit subkeys, K0 and K1. A derived key byte is obtained from the XOR of K0 and K1, and the byte at position 0 (K0 XOR K1) [0], is used in the first-round computation. The intermediate value is computed by XORing PT [0] with (K0 XOR K1) [0], and the result is passed through the PRINCE S-box. The resulting 8-bit S-box output is divided into its most significant nibble (bits 7-4) and least significant nibble (bits 3-0). The most significant nibble is used as the class label, resulting in 16 classes (0-15).
